Ecobike SX 5 Electric Bike
When the path becomes unpredictable, you need a bike you can rely on.

Who is this electric bike best suited for?
The Ecobike SX 5 electric bike is designed for riders who don't compromise when the asphalt gives way to unpaved trails. It is the ideal choice for anyone who needs a reliable, durable, and powerful mountain e-bike to venture further than the rest without hesitation. If you are looking for proven solutions and equipment that won't let you down, the SX 5 is the right choice for you.

Proven Bafang Drive System
A proven electric system provides a unique riding experience and reliable assistance. The powerful and low-maintenance Bafang rear hub motor with 250 W of power and 45 Nm of torque ensures you can easily conquer climbs and tackle even more demanding terrains. A modern controller ensures the optimal performance of the drive system while you enjoy the ride.

Integrated Battery for Long Range
The bike's frame is designed to fully integrate the battery into its construction. This not only ensures an aesthetic look but also durability and convenience when inserting and removing the battery. You can choose between two battery capacities, 522 Wh (14.5 Ah) or 630 Wh (17.5 Ah), which allow for a range of up to 140 km on a single charge, giving you the freedom to explore without limits.

Comfort and Control on the Trail
To ensure the SX 5 won't let you down, it is equipped with durable components. The excellent SunTour XCM fork with 100 mm of travel absorbs shocks. Robust TRC Dryjack 29" x 2.1 tires provide grip on various surfaces, while Alhonga hydraulic brakes ensure safe and reliable stopping in all conditions.

Reliable Shimano Components
The bike is equipped with high-quality Shimano shifting components. The combination of a Shimano Altus front derailleur (3 speeds) and a Shimano Alivio rear derailleur (9 speeds) provides a wide range of gear ratios (3x9) and ensures precise and reliable shifting, regardless of the terrain's difficulty.

Easy Control
Mounted on the handlebar is a clear and easy-to-use Ecobike C300U LCD display. It allows you to monitor all key ride information, such as battery status, current speed, and the selected assistance level. This enables you to easily adjust the settings to your needs and fully focus on the path ahead.
What do you get with your purchase?
- Ecobike SX 5 electric bike
- Charger
- User manual
- Warranty: 1 year
- Service and support at the address Tržaška cesta 222, 1000 Ljubljana.
Technical Specifications
| Motor | BAFANG SWX02, rear hub, 36V, 250W, 45 N.m |
| Battery | Li-ion, 36V, 14.5 Ah (522 Wh) or 17.5 Ah (630 Wh), EVE/Greenway cells |
| Range | up to 140 km |
| Charging time | 7 - 9 hours |
| Battery lifespan | approx. 700 charges |
| Display | Ecobike C300U, LCD monochrome |
| Frame | 20" hydroformed aluminum |
| Fork | SunTour XCM, 100 mm travel |
| Wheels | 29" reinforced, triple-chamber / Sapim spokes |
| Tires | 29" x 2.1 TRC Dryjack |
| Brakes | Alhonga HJ-HT472, hydraulic |
| Front derailleur | Shimano Altus, 3-speed |
| Rear derailleur | Shimano Alivio, 9-speed |
| Shifters | Shimano SL-M2000 Altus 3x9 |
| Cassette | SunRace 13-32T, 9-speed |
| Crankset | Shimano FCM371, 44 x 32 x 22T |
| Chain | KMC X9 |
| Handlebar | Zoom 720 mm, 31.8 mm |
| Stem | Promax 10° / 90 mm |
| Saddle | Velo VL-3363 |
| Seatpost | PROMAX SP-252 (27.2 mm x 350 mm) |
| Maximum load | 125 kg |
| Bike weight | 25.8 kg |
| Effective top tube length | 610 mm |
| Head tube height | 160 mm |
| Seat tube length | 508 mm |
| Wheelbase | 1124 mm |
