Off-road electric scooter
ECO Speed 9
Go further, ride smoother, fold faster.
Specifications of
ECO Speed 9
Motor | |
---|---|
Drivetrain | Rear drive |
Nominal Power | 800 W |
Maximum Power | 1.200 W |
Speed | |
Limited Speed | 25 km/h |
Speed Modes | 3 speed modes |
Maximum Incline Angle | 15° |
Battery | |
Maximum Range | 50 km |
Battery Capacity | 15.6 Ah |
Battery Voltage | 48 V |
Charging Time | 8-10 hours with standard 2A charger (included) / 3-4 hours with fast 5A charger (not included) |
Charger Type | 1x Standard charger 2A / 1x Fast charger 5A |
Suspension | |
Front Suspension | Spring |
Rear Suspension | Spring |
Brakes | |
Front Brake | Disc mechanical 140 mm |
Rear Brake | Disc mechanical 140 mm / Electronic brake |
Tires | |
Tire Type | Pneumatic |
Front Wheel Size | 9" |
Rear Wheel Size | 9" |
Lighting | |
Front light, rear light, side LED strips. | |
Water Protection | |
IP54 - Protected from dust & light water splashes | |
Dimensions | |
Length | 122 cm |
Height | 124 cm |
Width | 66 cm |
Folded | |
Length | 122 cm |
Height | 57 cm |
Width | 66 cm |
Other | |
Recommended Height | 160-200 cm |
Net Weight | 22 kg |
Load Capacity | 120 kg |
Warranty | 1 year |
-
Comfort & Design
Weighing only 23 kg, the ECO Speed 9 combines portability with structural strength, supporting up to 120 kg load capacity. The 10-inch pneumatic tires with inner tubes provide shock absorption and reliable grip on asphalt and light uneven terrain. The reinforced deck with an extended raised rear section is ergonomically designed for long rides, giving riders additional stance options. A dual suspension system enhances comfort, reducing fatigue during extended commutes. The folding stem mechanism allows the scooter to be folded in under 3 seconds, ensuring easy transport and storage. Handlebar controls provide intuitive access to lighting, turn signals, and mode switching. With its lightweight frame, compact design, and comfort-oriented ergonomics, the ECO Speed 9 is ideal for riders seeking an efficient, foldable scooter for city commuting and daily mobility.
-
Maintenance
The ECO Speed 9 requires regular care to sustain peak performance. Tires should be checked for proper inflation and inspected for punctures, with timely replacement of worn tubes. Disc brakes must be monitored for pad wear and rotor condition, while the electronic braking system should be tested periodically for responsiveness. Suspension forks and pivot points should be inspected for play or looseness after heavy use. Electrical connectors, switches, and LED lighting should be kept clean and moisture-free to ensure reliable operation. The 48 V 15.6 Ah battery should be charged with the correct charger and stored at 40–60% charge in a cool, dry environment if unused for long periods. Regular torque checks on axle bolts, stem clamps, and folding mechanisms help preserve stability and safety. With routine servicing, the ECO Speed 9 remains a dependable and efficient choice for daily mobility.
